22.32.0.230.4420 Finder Modular Contactor 25A 2P NC 230V AC/DC

The 22.32.0.230.4420 (alternate code 223202304420) is a Finder 25A modular contactor featuring 2-pole normally closed (NC) configuration with 230V AC/DC coil voltage. This modular contactor, also known as a lighting contactor, heating contactor, or installation contactor, is designed for reliable switching of electrical loads in industrial and commercial applications.

This Finder 25A modular contactor provides dependable control for lighting circuits, heating systems, and pump installations across commercial and industrial environments. Engineered with Finder's renowned quality standards, it delivers silent operation and visual status indication, making it ideal for noise-sensitive applications like hotels and office buildings.

Key Features

• 25A Current Rating with AgSnO2 Contacts: Silver tin oxide contact material ensures reliable switching performance and extended operational life, even under demanding load conditions
• AC/DC Silent Coil Technology: Eliminates buzzing and humming noise during operation, making it perfect for installations in quiet environments like hotels and offices
• Dual Status Indication: Mechanical indicator plus LED provides both visual confirmation of contact position and electrical status, simplifying troubleshooting and maintenance
• Compact DIN Rail Design: At just 17.5mm wide, this space-efficient design maximizes panel real estate while maintaining full 25A switching capability
• 2-Pole Normally Closed Configuration: Provides fail-safe operation where circuits remain energized during normal operation and de-energize when the coil is activated
• Flexible Cable Compatibility: Accommodates up to 6mm² flexible cables, providing versatility for various wiring requirements and installation scenarios
• 3kA Short Circuit Protection: Built-in protection capability enhances system safety and reduces the need for additional protective components

Applications

This Finder modular contactor is specifically designed for hotel room lighting control, garden and night lighting systems, office lighting automation, and pump control applications. Its normally closed configuration makes it particularly suitable for safety-critical installations where loads must remain energized during normal operation, such as emergency lighting systems, heating circuits that require fail-safe operation, and security lighting installations.

Standards and Sustainability

The unit carries comprehensive international certifications including UKCA, CE, EAC, and UL approvals, ensuring compliance with global electrical standards. The IP20 rating provides protection against finger contact and solid objects larger than 12mm, making it suitable for standard electrical panel installations.

Manufactured by Finder in Italy, this modular contactor (order code: 22.32.0.230.4420) represents decades of Italian engineering expertise in electromagnetic switching technology.

Frequently Asked Questions

What cable sizes can I connect to the 22.32.0.230.4420 Finder modular contactor?

This Finder modular contactor accommodates flexible cables up to 6mm² maximum size. The terminal design provides secure connections for both solid and stranded conductors within this range, ensuring reliable electrical contact for the full 25A current rating.

What is the difference between NC and NO configuration in modular contactors?

This 22.32.0.230.4420 features normally closed (NC) contacts, meaning the circuit is complete when the coil is de-energized and opens when 230V is applied to the coil. This is opposite to normally open (NO) contactors and is ideal for fail-safe applications where you want the load to remain energized during normal operation.

What are the mounting dimensions for installation planning?

The contactor measures 17.5mm wide, 88.8mm high, and 60.8mm deep, designed for standard 35mm DIN rail mounting. At just 0.09kg, it's lightweight and requires minimal panel space while maintaining full 25A switching capability for demanding applications.

Can this contactor handle both AC and DC loads with the same coil?

Yes, the 22.32.0.230.4420 features Finder's AC/DC coil technology, allowing it to operate on either 230V AC or 230V DC supply voltage. The silent coil design eliminates noise regardless of the supply type, making it versatile for various control system configurations.
