22.64.0.024.4310 Finder Modular Contactor 63A 4P NO 24V AC/DC

The 22.64.0.024.4310 (alternate code 226400244310) is a Finder 63A 4-pole modular contactor designed for reliable switching in electrical installations. This modular contactor, also known as a lighting contactor, heating contactor, or installation contactor, operates on 24V AC/DC and features four normally open contacts for versatile control applications.

This 63A modular contactor provides efficient and reliable switching control for medium to high-power electrical loads in commercial and industrial environments. Its compact modular design makes it ideal for modern electrical panels where space efficiency is crucial, while the AC/DC silent coil technology ensures quiet operation in noise-sensitive applications.

Key Features

• 63A Current Rating: Handles substantial electrical loads up to 63 amperes, making it suitable for heavy-duty lighting circuits, heating systems, and motor control applications
• 4-Pole Configuration: Four normally open contacts provide comprehensive control over three-phase plus neutral circuits, essential for balanced load switching
• 24V AC/DC Silent Coil: Versatile coil voltage compatibility with silent operation technology reduces noise in office buildings, hotels, and residential applications
• DIN Rail Mounting: Standard 35mm DIN rail compatibility ensures quick installation and easy integration into existing electrical panels
• AgSnO2 Contact Material: Silver tin oxide contacts provide excellent arc quenching properties and extended operational life, reducing maintenance requirements
• Mechanical Indicator: Visual contact position indication allows technicians to quickly verify the contactor's operational status during maintenance
• Compact Dimensions: At just 53.5mm wide, this contactor maximises panel space utilisation while maintaining full 63A switching capacity
• 16mm² Cable Capacity: Accommodates flexible cables up to 16mm², providing adequate conductor sizing for high-current applications

Applications

This Finder modular contactor excels in commercial and light industrial switching applications including hotel room lighting control systems, outdoor garden and security lighting installations, office building lighting circuits, and pump control systems. The 24V coil voltage makes it particularly suitable for building management systems and automated lighting controls where low-voltage control circuits are preferred for safety and energy efficiency.

Standards and Compliance

The contactor meets rigorous international safety standards with UKCA, CE, EAC, and UL certifications, ensuring compliance across multiple markets. The IP20 protection rating provides suitable protection for standard electrical panel environments, while the 3kA short-circuit protection rating offers robust fault protection.

Manufactured by Finder in Slovenia, order code 22.64.0.024.4310.

Frequently Asked Questions

What is the maximum cable size that can be connected to the 22.64.0.024.4310 modular contactor?

The Finder 22.64.0.024.4310 accepts flexible cables up to 16mm² maximum size. This cable capacity is well-suited for the 63A current rating and provides adequate conductor cross-section for high-current applications while maintaining safe current density.

What are the mounting dimensions for this 63A modular contactor?

The contactor measures 53.5mm wide, 95.8mm high, and 60.8mm deep, weighing 0.4kg. It mounts on standard 35mm DIN rail, requiring just over 5cm of panel width, making it space-efficient for high-density electrical installations.

Can this modular contactor be used for both AC and DC control circuits?

Yes, the 24V coil is designed for both AC and DC operation, providing flexibility in control system design. The silent coil technology ensures quiet operation regardless of whether AC or DC control voltage is used, making it suitable for noise-sensitive environments.

What is the difference between this modular contactor and a standard contactor?

This modular contactor is specifically designed for DIN rail mounting in electrical panels, featuring a compact profile optimised for space efficiency. Unlike bulkier standard contactors, it integrates seamlessly with other modular devices and includes features like mechanical indication and silent coil operation for modern building installations.

Where can I buy 22.64.0.024.4310 Finder Modular Contactor 63A 4P NO 24V AC/DC in the UK?

CSE Distributors supplies this Finder modular contactor from warehouses in Wooburn Green and Southampton, offering same-day dispatch and next-day delivery nationwide. As an official Finder distributor with over 50 years of experience and hundreds of positive reviews, CSE provides genuine products with full warranty and expert technical support.
