ESB16-11N-06 ABB Modular Contactor 16A 2P 1NO+1NC 230V AC/DC Coil 1SBE111111R0611

The ESB16-11N-06 (1SBE111111R0611) is an ABB 16A modular contactor featuring 2-pole operation with 1NO+1NC configuration and a 230V AC/DC coil design. Modular contactors, also known as lighting contactors, heating contactors, or installation contactors, are essential switching devices for controlling electrical loads in residential and commercial installations.

This ABB modular contactor provides reliable switching and control for lighting circuits, heating systems, ventilation equipment, EV charging stations, motors, and pumps. Its compact DIN rail mounting design and hum-free operation make it ideal for installation in distribution boards and control panels where space is limited and quiet operation is essential.

Key Features

• 16A Current Rating: Handles substantial electrical loads safely, making it suitable for most lighting and heating circuits without oversizing
• AC/DC Coil Design: Eliminates humming noise during operation, ensuring quiet performance in residential and office environments
• 1NO+1NC Contact Configuration: Provides both normally open and normally closed contacts in a single device, offering flexible switching options for complex control circuits
• 230V Coil Voltage: Matches standard UK mains voltage, simplifying installation and reducing the need for additional transformers
• Compact DIN Rail Mounting: At just 17.8mm width, maximises space utilisation in distribution boards while ensuring secure panel installation
• IP20 Protection Rating: Provides appropriate protection for indoor electrical installations in dry environments
• Wide Operating Temperature Range: Functions reliably from -25°C to +55°C, suitable for various installation environments including unheated buildings
• 6mm² Maximum Cable Capacity: Accommodates flexible cables up to 6mm², providing adequate connection options for most installation requirements

Applications

The ESB16-11N-06 modular contactor is widely used in residential, commercial, and light industrial applications for switching lighting circuits, electric heating systems, ventilation fans, and small motors. It's particularly suitable for automatic control systems where remote switching is required, such as time-controlled lighting in car parks, heating control in commercial buildings, and pump control in water systems. The compact design makes it ideal for installation in distribution boards where multiple circuits need individual control.

Standards and Sustainability

This ABB modular contactor carries UKCA, CE, and UL certifications, ensuring compliance with UK, European, and North American electrical standards. The IP20 rating confirms suitability for standard indoor electrical installations in dry environments.

Manufactured by ABB in Bulgaria, order code ESB16-11N-06 (1SBE111111R0611).

Frequently Asked Questions

What cable sizes can be connected to the ESB16-11N-06 modular contactor?

The ESB16-11N-06 can accommodate flexible cables up to 6mm² maximum size. This capacity is suitable for most 16A circuit applications and provides adequate connection options for both power and control wiring in typical lighting and heating installations.

What is the difference between this modular contactor and a standard relay?

The ESB16-11N-06 modular contactor is designed for higher current switching (16A) compared to standard control relays, making it suitable for directly controlling lighting and heating loads. It features a hum-free AC/DC coil design and robust contacts specifically engineered for frequent switching of electrical loads, whereas standard relays are typically used for low-current control applications.

How do I mount the ESB16-11N-06 in my electrical panel?

This modular contactor mounts directly onto standard 35mm DIN rail and occupies just 17.8mm width (approximately 1 module space). The compact dimensions of 85mm height × 17.8mm width × 64.8mm depth ensure it fits in most standard distribution boards alongside other DIN rail mounted devices.

Can this contactor be used for both AC and DC control circuits?

Yes, the ESB16-11N-06 features an AC/DC coil design that operates with both AC and DC control voltages at 230V. This versatility makes it suitable for various control system configurations and eliminates the need for separate contactors for different voltage types.
