ESB25-22N-06 ABB Modular Contactor 25A 4P 2NO+2NC 230V AC/DC Coil 1SAE231111R0622

The ESB25-22N-06 (1SAE231111R0622) is a 25A modular contactor manufactured by ABB, designed for reliable switching and control in electrical installations. This 4-pole modular contactor, also known as a lighting contactor, heating contactor, or installation contactor, features a versatile 2NO+2NC configuration with a 230V AC/DC coil for maximum application flexibility.

ABB's ESB25-22N-06 modular contactor delivers reliable switching performance for lighting, heating, ventilation systems, EV charging stations, motors and pumps. With its compact DIN rail design and hum-free operation, this contactor provides an ideal solution for modern electrical installations requiring dependable automated control.

Key Features

• Hum-Free AC/DC Coil Design: Eliminates noise and vibration during operation, making it suitable for noise-sensitive environments like offices and residential applications
• 25A Current Rating: Handles substantial loads up to 25 amperes, suitable for medium-duty lighting circuits, heating elements, and motor applications
• 4-Pole 2NO+2NC Configuration: Provides flexible switching arrangements with two normally open and two normally closed contacts for complex control schemes
• 230V AC/DC Universal Coil: Single coil works with both AC and DC control circuits, reducing inventory requirements and simplifying installation
• Compact DIN Rail Mounting: Space-efficient design at just 36mm width fits standard DIN rails and maximises panel density
• Wide Operating Temperature Range: Functions reliably from -25°C to +55°C, suitable for both indoor and outdoor installations
• 10mm² Cable Capacity: Accommodates flexible cables up to 10mm², providing adequate connection options for most applications

Applications

The ESB25-22N-06 modular contactor is extensively used in commercial and industrial installations for automated switching of lighting circuits, HVAC systems, electric heating elements, small motors, and pumps. Its compact form factor makes it particularly suitable for distribution boards, control panels, and automation cabinets where space is at a premium. The contactor is commonly specified in building services, industrial automation, and renewable energy installations including EV charging infrastructure.

Standards and Sustainability

This ABB modular contactor carries UKCA, CE and UL certifications ensuring compliance with European and North American safety standards. The unit features IP20 protection rating for standard electrical enclosure applications.

Manufactured by ABB in Germany, order code ESB25-22N-06.

Frequently Asked Questions

What cable sizes can the ESB25-22N-06 modular contactor accommodate?

The ESB25-22N-06 can accommodate flexible cables up to 10mm² maximum size, providing sufficient capacity for most 25A applications while maintaining secure terminations in the compact terminal design.

What is the difference between this modular contactor and a standard contactor?

Modular contactors like the ESB25-22N-06 are specifically designed for DIN rail mounting in distribution boards and feature compact dimensions (36mm width). Unlike larger industrial contactors, they're optimised for building services applications with hum-free operation and typically handle lighting, heating, and small motor loads.

What are the mounting dimensions for the ESB25-22N-06?

The ESB25-22N-06 measures 36mm wide, 85mm high, and 64.8mm deep, weighing just 0.25kg. It mounts directly onto standard 35mm DIN rail and requires minimal panel space, making it ideal for crowded distribution boards.

Can the ESB25-22N-06 be used for both AC and DC control circuits?

Yes, the ESB25-22N-06 features a universal 230V AC/DC coil that operates with both alternating and direct current control systems. This versatility eliminates the need for separate AC and DC variants and simplifies inventory management.
