H07RN-F Rubber Cable - 3 Core 6mm2 / HO7RN-F-3C-6

Code: HO7RN-F-3C-6

Buy H07RN-F Rubber Cable - 3 Core 6mm2 / HO7RN-F-3C-6 | Order By 1pm For Same Day Shipping | Free Delivery Over £150 *Conditions Apply |

per Metre
£3.41 ex VAT

342 Available


QtyAdd to Cart

H07RN-F Flexible Rubber Cable - 3 Core 6mm²
h07rn-f 3g 6mm2

Are you searching for a heavy-duty cable that can withstand even the toughest conditions? Look no further than the H07RN-F flexible rubber Cable. This high-quality cable is designed specifically to be a flexible and durable trailing cable, making it perfect for supplying energy for portable equipment in industries such as events, conferencing and sound studios.

In addition to this design remit,  the H07RN-F cable is also made from PCP neoprene, which means it is both oil, chemical and flame retardant. making it a sound choice for a range of equipment such as and including transformers, pumps, welders, grinders, temporary lighting cable, and feed cables to heavy mobile equipment that may be placed in low hazardous areas.

Along with a dispatch time of just 1-2 days and with it priced per meter, it's easy to get exactly the amount you need without the waste. Don't settle for less - choose the H07RN-F Rubber Cable for all your heavy-duty cable needs. your next project.

Technical Information

  • Number of cores: 3
  • Conductor CSA: 6.0mm²
  • Conductor material: Bare copper
  • Insulation material: Cross-linked Elastomer
  • Core colours: Green/Yellow, Brown and Blue
  • Jacket material: Cross-linked Elastomer
  • Approx. Overall diameter: 15.5mm
  • Jacket colour: Black
  • Voltage rating: 450/750V
  • Cable weight: 0.371kg per metre
  • CPR Euroclass: Eca
Oil Resistant Yes
Sheath Colour Black
Conductor Size 6mm²
Harmonised Code H07RN-F
Voltage 450/750V
Stranding 84/0.3
Sheath Material Cross-linked Elastomer
Thickness of Insulation 1mm
Conductor Material Bare Copper
Max. Amps 63A
Number of Cores 3
Min. Diameter 14.1 mm
Max. Diameter 18 mm
UV Resistance Yes
CPR Rating Eca
Bending Radius (Dynamic) 6 To 8 x Outer Diameter Of The Cable
Bending Radius (Static) 4 x Outer Diameter Of The Cable
Item Code HO7RN-F-3C-6
Alternate Code H07RN-F-3C-6
MPN 3X6TITANEX90
Manufacturer Titanex
Unit of Measure Metre
Pack QTY 1
Net Weight 0.35 kg
Gross Weight 0.35 kg
EAN 3427680014733
Commodity Code 85444991
Country of Origin France

Titanex H07RN-F Datasheet
