060-110866 Danfoss KP36 Pressure Switch Setting range: 2 to 14

Code: 060-1108

Buy 060-110866 Danfoss KP36 Pressure Switch Setting range: 2 to 14 | Order By 2pm For Same Day Shipping | Free Delivery Over £150 | Log In For Better Pricing

per Each
Was £56.06
£53.25 ex VAT

2 Available

Min Qty: 1

060-110866 Danfoss KP36 Pressure Switch Setting range: 2 to 14 | Danfoss KP pressure switches are used for regulating, monitoring and alarm systems in industrial applications.

The KP series are suitable for gaseous media and air. They are fitted with a single-pole switch changeover (SPDT), and can control single-phase ac motors of up to 2 kW directly.
Characteristic Value
Type KP36
Weight 0.295 Kg
Ambient temperature [oC] -40 - 65oC
Ambient temperature [oF] -40 - 149oF
Ambient temperature [oC] -40 - 65oC
Ambient temperature range [oF] -58 - 158oF
Approval c UL us UL353, CS C22.2, c UL us UL873, CS C22.2, CCC, CE, EAC, FM, RINA, RMRS
Contact function SPDT
Contact rating AC1=16 A, 400 V
Contact rating AC15=10 A, 400 V
Contact rating AC3=16 A, 400 V
Contact rating DC13=12 W, 220 V
Contact rating LR 112 A, 400 V
Differential 0.70 - 4.00 bar
Differential 10.00 - 58.00 psi
Electrical conn. comments Rubber cable gland
Electrical connection size 6-14 mm
Enclosure rating IP30
Max. test pressure Pe 22.0 bar
Max. Working Pressure 17.0 bar
Max. Working Pressure 245 psig
Max. working pressure Pe 17.0 bar
Max. working pressure Pe 245.0 psig
Nema rating 1
Pressure connection standard ISO 228-1
Pressure connection type G - 1/4 Male
Pressure range category Medium pressure
Pressure sensing element Bellows
Product description Pressure Control
Product group Switches and thermostats
Product name Pressure switch
Refrigerants HCFC/Non flam HFC
Regulation range Pe 2.00 - 14.00 bar
Regulation range Pe 29.00 - 203.00 psig
Reset function AUTO
UL approval file name E31024
UL approval file name MH27572

Item Code 060-1108
Alternate Code 060-110866
Make Danfoss
Unit of Measure Each
Commodity Code 90322000
Country of Origin PL
EAN 5702423146635
Pack QTY 1
Net Mass (Kg) 0.3
Gross Mass (Kg) 0.33
