H07RN-F Rubber Cable - 3 Core 2.5mm2 / HO7RN-F-3C-2.5

    Categories

    HO7RN-F-3C-2.5Titanex H07RN-F Cable
    HO7RN-F-3C-2.5
    Titanex H07RN-F Cable
    Code: HO7RN-F-3C-2.5

    Buy H07RN-F Rubber Cable - 3 Core 2.5mm2 / HO7RN-F-3C-2.5 / 2.5mm x 3 Core | Order By 1pm For Same Day Shipping |

    per Metre
    £1.48 ex VAT

    8529 Available


    QtyAdd to Cart

    Product Description
    2.5mm x 3 Core H07RN-F Cable
    H07RN-F Rubber Cable - 3 Core 2.5mm2
    h07rn f 3g2.5

    Dispatch Time: 1-2 Days
    Price Per Meter. Cut to length. Enter Number of Meters Required

    The H07RN-F cable 3 Core 2.5mm2 cross-sectional area (h07rn f 3g2.5) is priced per meter and is designed primarily as a trailing cable for use in the supply of energy for portable or mobile equipment. Heavy duty Harmonized cables are not only robust but also extremely flexible. PCP neoprene is also oil and flame retardant. Typical applications of the H07RN-F cable include transformers, pumps, welders, grinders, temporary lighting cable and feed cables to heavy mobile equipment.

    2.5mm x 3 Core H07RN-F Cable Technical Information

    • Number of cores: 3
    • Conductor CSA: 2.5mm²
    • Conductor material: Bare copper
    • Insulation material: Cross-linked Elastomer
    • Core colours: Green/Yellow, Brown and Blue
    • Jacket material: Cross-linked Elastomer
    • Approx. Overall diameter: 11.93mm
    • Jacket colour: Black
    • Voltage rating: 450/750V
    • Cable weight: 0.2kg per metre
    • CPR Euroclass: Eca
    Technical Information
    Oil Resistant Yes
    Sheath Colour Black
    Conductor Size 2.5mm²
    Harmonised Code H07RN-F
    Voltage 450/750V
    Stranding 32/0.2
    Sheath Material Cross-linked Elastomer
    Thickness of Insulation 0.9mm
    Conductor Material Bare Copper
    Max. Amps 36
    Number of Cores 3
    Min. Diameter (mm) 10.9
    Max. Diameter (mm) 14
    UV Resistance Yes
    CPR Rating Eca
    Bending Radius (Dynamic) 6 To 8 x Outer Diameter Of The Cable
    Bending Radius (Static) 3 x Outer Diameter Of The Cable If OD< or = 12Mm ; 4x If OD > 12mm
    Commercial Information
    Item Code HO7RN-F-3C-2.5
    Alternate Code H07RN-F-3C-2.5
    MPN 3X2.5TITANEX90
    Manufacturer Titanex
    Unit of Measure Metre
    Pack QTY 1
    Net Mass (kg) 0.19
    Gross Mass (kg) 0.19
    EAN 3427680014627
    Commodity Code 85444991
    Country of Origin France
    Downloads

    Titanex H07RN-F Datasheet
