Gewiss Surface Mounted Plastic Junction Boxes



Gewiss Enclosures and accessoriesThe Gewiss range of surface mounting, watertight plastic enclosures offer a simple low-cost solution for general use. They are ideal for mounting small electrical items such as transformers, terminals, starters, etc.
CSE hold in stock the most popular items as shown in the price list below. All other products are available to order.

Features and benefits

  • Modular sizes.
  • Available with either low or deep lid.
  • Available with opaque grey or transparent lids.
  • (Colour: Grey RAL7035).
  • Temperature rating of 75ºC.
  • (120ºC Temperature rating available to order).
  • Mounting plates include self tapping screws for easy use
  • Din-Rail can be cut to size and mounted directly into the self-tapping holes in the back of the enclosure base.

The part numbers below are for plain walled enclosures. Integral flexible plastic glands are also available – please enquire. Click on the part numbers to buy on-line.

Gewiss Plastic Enclosures

Part Nº Internal Dimensions (mm)LxHxD Backplate Type Lid Type
GW44204 100 x 100 x 50 N/A Shallow
GW44205 120 x 80 x 50 N/A Shallow
GW44206 150 x 110 x 70 N/A Shallow
GW44207 190 x 140 x 70 GW44615 Shallow
GW44208 240 x 190 x 90 GW44616 Shallow
GW44209 300 x 220 x 120 GW44617 Shallow
GW44210 380 x 300 x 120 GW44618 Shallow
GW44211 460 x 380 x 120 GW44619 Shallow
GW44214 100 x 100 x 120 N/A Deep
GW44215 120 x 80 x 120 N/A Deep
GW44216 150 x 110 x 140 N/A Deep
GW44217 190 x 140 x 140 GW44615 Deep
GW44218 240 x 190 x 160 GW44616 Deep
GW44219 300 x 220 x 180 GW44617 Deep
GW44220 380 x 300 x 180 GW44618 Deep
GW44221 460 x 380 x 180 GW44619 Deep

  Galvanized Metal Mounting Plate C/w Screws

The table below shows the range of metal backplates; Insulated plastic backplates are available to order, please enquire.

CSE Part Nº To suit enclosure size
GW44615 190 x 140 x 70
GW44616 240 x 190 x 90
GW44617 300 x 220 x 120
GW44618 380 x 300 x 120
GW44619 460 x 380 x 120
